Redox Flow Cell Test Fixture

The Redox Flow Cell Test Fixture is specifically designed for use with our 857 Redox Flow Cell Test System. All non-metallic flow paths are made with non-corrosive, chemically resistant plastics only! We offer multiple assembly configurations to allow for various gap, electrode type, and thickness.

Cell fixture specifically designed for use with the Scribner 857 Redox Flow Cell Test System
Cell area from 5 to 25 cm2
All non-metallic flow paths made with noncorrosive, chemically resistant plastics only
115 V or 230 V cell heaters
Operating temperature up to 120o C
SGL Carbon SIGRACELL® graphite felt
PTFE (Teflon®) flow frames
Ultra-high purity, sealed POCO graphite flow fields with precision machined serpentine or interdigitated flow pattern custom flow patterns available)
Custom flow patterns available
Gold-plated copper current collectors
Anodized aluminum end plates with reactant input/output ports, Swagelok fittings, cartridge heaters & thermocouple well
Gaskets, gasket templates and additional hardware such as bolts, washers, fittings and O-rings
